Duct Type Industrial Energy Saving Air Conditioner

Introducing the Tongbaote high quality Duct Type Industrial Energy Saving Air Conditioner, a cutting-edge solution for industrial cooling needs. Derived from the technology of large-scale central air conditioning systems, this domestically produced evaporative cooling air conditioner combines the exceptional efficiency of water-cooled evaporation with the convenience of small-scale split-system control.

Boasting an energy efficiency ratio (EER) ranging from 4.5 to 5.5, the Tongbaote Duct Type Industrial Energy Saving Air Conditioner maintains its high performance even in extreme heat, effectively addressing the issues faced by traditional air-cooled systems when ambient temperatures exceed 43°C.

Designed with cost-effectiveness and performance in mind, this air conditioner utilizes an optimal power range for each module, allowing for standalone installation or integration into a small-scale central air conditioning system at a fraction of the cost of traditional systems. Furthermore, its maintenance requirements are minimal, requiring only routine cleaning and inspections to ensure smooth operation, saving you time and resources.

The standard models offer cooling capacities of 22KW and 35KW, with airflow options of 5000m³/h and 8000m³/h to suit various industrial applications. Customizable large-scale floor-standing modular units are also available to meet specific requirements. Featuring an efficient wet-type water curtain cooling system, the air conditioner connects the indoor and outdoor units using PVC water pipes, eliminating the need for complex refrigerant piping and insulation. This simplified installation process allows for standalone or combined operation, providing the flexibility to cool specific areas as needed while enjoying the comfort and efficiency of a central air conditioning system.

The Tongbaote Duct Type Industrial Energy Saving Air Conditioner is the ideal choice for industrial environments seeking a cost-effective, energy-efficient, and easy-to-maintain cooling solution. Experience the power of evaporative cooling with Tongbaote today.

Feature And Application

This air conditioner has many advantages. It saves energy and is highly efficient in cooling, with an energy-saving range of 40 - 50%. The cooling capacity is large, and the cooling area is more than 150 - 200 square meters. The installation is easy and the cost is not high, and it can be installed by non-professional air conditioning technicians. It can adapt to a high ambient temperature and has a strong cooling effect. It has functions such as cooling and dehumidification, and the internal unit is installed flexibly, and the external unit is connected simply. It adopts intelligent control and can be remotely operated by mobile phones. Maintenance is easy, and the filter screen is easy to clean. The performance is stable, and high-quality components are configured. It is widely applicable to various types of factories such as shoe factories and food factories.

Product features

1. Low power consumption, large cooling capacity. Compared with traditional air-cooled first-level energy-efficient air conditioners, it saves 40-50% energy.

2. Large cooling area. The single unit's cooling capacity can reach 22KW-35KW, and it can provide cooling for 150-200 square meters.

3. Simple installation, low installation cost. No need for professional air conditioning technicians. Plumbing and electricians can install it.

4. Suitable for high ambient temperatures. It can provide strong cooling even at 45-60°C.

5. Has cooling and dehumidification effects. The indoor minimum temperature can be reduced to 16 degrees.

Specialized air-water-cooled energy-saving air conditioner introduction

1. Product features

The air-water-cooled energy-saving air conditioner can provide normal cooling without failure even in an environment temperature range of 50-60°C.

2. Energy input

It can be equipped with a photovoltaic direct-drive module. It can prioritize photovoltaic or use auxiliary power from the grid. It can be used with or without photovoltaic.

3. Cooling features

When the ambient temperature is below 25°C, the natural cooling mode does not activate the compressor. In the 25-35°C mixed cooling mode, the compressor assists in cooling. In the 35°C above cooling mode, the compressor starts to cool.

4. Cooling energy efficiency ratio

Compressor cooling mode COP = 4.6, mixed mode COP = 5-8, natural cooling mode COP = 10 or above.

5. Comprehensive energy-saving rate

Compared with air-cooled air conditioners, the annual cooling energy-saving rate is 50%-80% (depending on the regional environment).

6. Main application scenarios

Suitable for high-voltage substations, high-voltage frequency converter rooms, low-voltage distribution rooms, low-voltage frequency converter rooms, communication base stations, data centers, etc., where there is a large amount of electrical heat and requires year-round cooling.

7. Working mode

It automatically switches working modes based on the ambient temperature and return air temperature. Mechanical cooling mode / compressor cooling, mixed mode / compressor-assisted cooling, natural cooling mode / compressor shutdown.
